Steelgrip™ Conveyor Belt Lacing

  • $ 0.01


Call or Email for current price & Availability

(951) 764-3678  himarksales@gmail.com

Equal to FLEXCO Clipper Lacing

Time-tested and proven dependable, the strength of Steelgrip lacing is enhanced due to the common bar, which yields a continuous lacing strip for the width of the belting. Thus, the tension is distributed across the entire belt width. While made from a special steel that allows the points to pierce the belt carcass, the teeth are designed to enter the belt fabric without cutting the longitudinal strength members of the belting.

Metal Specifications

Galvanized

Standard for sizes 00, 1, and 7. Good for abrasion utilizing a low-carbon steel. Galvanizing provides some resistance to elements. Magnetic and poor chemical resistance.

Carbon Steel

Standard for sizes 15 through 45. Good for abrasion utilizing a low-carbon steel, which has good forming characteristics, allowing easy installation. Magnetic and poor chemical resistance.

Stainless Steel

A nickel chrome stainless steel that offers excellent resistance to fatty acids and wash-down chemicals, also good for mechanical abrasion. Excellent for use where food and sanitation requirements are high. Basically non-magnetic.

Steelgrip lacing comes in 8 sizes for belts from 1⁄16″ to 3⁄8″ thickness. The lacing is cross-scored so that it can easily be broken by hand to exactly fit any belt width exactly.

Steelgrip Belt Thickness

Belt MIN. PULLEY SIZE
1/16" 1" 00
1/16" – 3/32" 1 1/2 " 1A
3/32" – 9/64" 2" 7
1/8" – 5/32" 2 1/2 " 15
5/32" – 3/16" 3" 20
1/4" – 9/32" 5" 27
9/32" – 5/16" 7" 35
5/16" – 3/8" 9"

45

Steelgrip Belt Holder

To speed the installation of Steelgrip flexible belt lacing, each tool comes complete with changeable end blocks and 3 gauge pins to install #1–7, #15–20, and #27. Bolt-down holders secure the belt in position for correct installation. The gauge pin assures proper alignment of the fastener to the belt. Tools can be purchased in 12″, 24″, 36″, and 48″ widths.

Number
SGBH-12
SGBH-24
SGBH-36
SGBH-48
